AEROlite® PSM Universal Graphite Sheet Manufacturer | SS316L Tanged Core

TBJ-UTEX is a specialist manufacturer of Aerolite® PSM Universal Reinforced Graphite Sheets in Johor, providing a premium sealing solution manufactured to performance levels equivalent to leading international standards (e.g. KLINGER® PSM, TOMBO®). By mechanically clinching high-purity flexible graphite to a 0.1mm tanged (perforated) 316L stainless steel insert, PSM Universal offers maximum blowout resistance and structural integrity for high-pressure steam and hydrocarbon services worldwide.

Feature	Specification
Material Construction	High-Purity Flexible Graphite (>98% Carbon)
Metal Insert	0.1mm Tanged (Perforated) 316L Stainless Steel
Temperature Range	-200°C to +450°C (Steam) / Up to 3000°C (Non-Oxidizing)
Max Pressure	Up to 140 Bar (Subject to installation)
Chemical Resistance	pH 0-14 (Except strong oxidizing agents)
Equivalency	High-performance drop-in for KLINGER® PSM & TOMBO®
Logistics	Worldwide Export from our Johor Bahru facility

Why Choose AEROlite® PSM Universal?

The "Universal" designation means this grade is engineered for the widest possible range of industrial applications. Our AEROlite® PSM utilizes a mechanical tanged bond, which eliminates the need for adhesives that can fail at high temperatures. This ensures the graphite remains locked to the 316L metal core, providing superior handleability and high blowout resistance in pipelines, heat exchangers, and refineries.

Rapid Logistics for Global Energy Hubs

As a direct manufacturer, we maintain significant inventory of PSM sheets in standard thicknesses (1.0mm to 3.0mm) for rapid supply to Pasir Gudang and Pengerang refineries. We provide full material traceability and certified global shipping to ensure international industrial projects receive high-performance sealing solutions with minimal lead times.
